General Specifications

• Faders: 12 x 100mm touch-sensitive, motorised faders
• Screens: 1 x 17” LCD high-brightness, high-resolution touchscreen
• TFT Screens: 18 x Full Colour TFT LCD Displays
• Redundancy: Internal PSUs x 2
• Input Channels: 80 Input Channels (Mono)
• 2 Solo Busses
• 12 input x 8 output Full Processing Matrix
• 12 Control Groups (CGs)
• Graphic Eq 12 x 32-band
• Internal FX: 6
• Spice Rack: 6 Internal Spice Rack Slots
• 20 Mustard Processing Strips
• 24 Nodal Processing 4 Band Parametric EQ / Dynamic EQ
• Stadius 32-bit local I/O
• Up to 4 MADI interfaces or up to 2 redundant MADI interfaces at 48kHz or 2 interfaces at 96kHz
• MultiMode Optocore Interface (Optional)
• Sample Rate: 48kHz or 96kHz
• GPI: 2 Jack (2 inputs)
• GPO: 2 GPO Jack (2 outputs)
• 2 x DMI Slots (up to 64 I/O per slot)

Audio Specification

• Sample Rate: 48kHz or 96kHz
• Processing Delay: 0.5ms Typical (Mic in to Line out, no channel Processing)
• Internal Processing: Up to 40-bit, Floating Point
• A>D & D>A: 32-bit Converter Bit Depth
• Frequency Response: +/- 0.2dB (20Hz – 20kHz)
• THD+N (Mic In to AES Out): <0.002% @ 1kHz, 0dB gain, -10dBFS out, 22Hz-20kHz
• THD+N (AES In to Line Out): <0.002% @ 1kHz, +16dBu out, 22Hz-20kHz
• Channel Separation/Crosstalk (Mic In to Line Out): >100dB @ 10kHz
• Residual Output Noise: <93dBu Typical (20Hz – 20kHz)
• Equivalent Input Noise (EIN): <-127.5dBu A-weighted, 22Hz – 20kHz
• Maximum Output Level: +22dBu
• Maximum Input Level: +22dBu

Processing Channel Specification
Input Channel

• 80 Input Channels (Mono)
• Both Mustard and SD processing on all channels
• Main & Alternative input
•  Analogue Gain
•  Phase Inversion Control
•  Gain Tracking
•  Digital Trim (-40dB to +40dB)
•  Variable Delay (0ms to 1.3s)
•  DiGiTube
•  HPF/LPF (-24dB/Oct)
•  4 Band Parametric EQ / Dynamic EQ
•  DYN 1: Compressor, Multiband Compressor, De-esser
•  DYN 2: Gate, Duck, External Input Compressor
•  EQ/Dyn Order Control
•  2 Insert Points per Channel
•  Channel Mute & Hard Mute
• Channel Direct Outputs

24 Aux/Sub-Group Busses

• Digital Trim (-20dB to +60dB)
• Variable Delay (0ms to 1.3s)
• DiGiTube
• Merge Input
• Tone Generator
• HPF/LPF (-24dB/Oct)
• 8 Band EQ: 4 Band Parametric EQ and 4 Band
  Parametric or Dynamic EQ
• DYN 1: Compressor, Multiband Compressor, Desser
• DYN 2: Gate, Duck, External Input Compressor
• EQ/Dyn Order Control
• 2 Insert Points per Channel
•  Channel Mute & Hard Mute
  12 input x 8 output Full Processing Matrix
  12 Control Groups (CGs)
  2 Solo Busses
  12 x 32-band GEQs
  8 Internal Stereo FX ProcessorsDelays
• Audio Enhancer
• Choruses
•  Pitch Shifters
•  Reverbs
• 6 Internal Spice Rack Slots
• 6 band Dynamic Multiband Compressor/Expander
• 6 band Dynamic EQ

Mustard Processing

• 20 Mustard Processing Strips
•  Tube
•  Tube Emulation
•  HPF/LPF (-24dB/Oct)
•  4 Band EQ: 2 Band Parametric EQ and 2 Band
  Parametric EQ or All Pass Filters
•  DYN 1: Classic RMS/Peak Compressor, Vintage VCA
  Compressor, Optical Compressor, FET Limited
•  DYN 2: Gate, Ducker
  24 Nodal Processing 4 Band Parametric EQ / Dynamic EQ
  • DYN 1: Compressor, Multiband Compressor, Desser
  • DYN 2: Gate, Duck, External Input Compressor
  Multiband Compressors available on every channel, Buss
  and Nodal Processor
  Dynamic EQs available on every channel, Buss and Nodal
  Processor
  DiGiTuBes available on every channel & Buss
  Virtual Soundcheck
  True Solo function
