Less than 3ms INPUT to OUTPUT, connect with TF5 and NY64-D using Dante, Dante Receive Latency set to 0.25ms (one way), Fs=48kHz
Total harmonic distortion
Less than 0.1% +4dBu@20Hz-20kHz into 600Ω, Gain=+66dB / Less than 0.05% +4dBU@20Hz-20kHz into 600Ω, Gain=-6dB, INPUT to OUTPUT, Fs=44.1kHz, 48kHz *Measured with a -18dB/octave filter @80kHz
Frequency response
+0.5, -1.5dB 20Hz-20kHz, refer to the nominal output level @1kHz, INPUT to OUTPUT, Fs=44.1kHz or 48kHz
Dynamic range
108 dB, INPUT to OUTPUT, Gain=-6dB / 112 dB, DA Converter
Hum & noise level
Equivalent input noise
-128dBu, Gain=+66dB *Measured with A-weighting filter
Residual output noise
-88dBu, ST master off *Measured with A-weighting filter
Crosstalk
-100dB, adjacent INPUT/OUTPUT channels, Input Gain = -6dB *Measured with a -30dB/octave filter @22kHz
Heat dissipation
100-240V, 50/60Hz, 43.5kcal/h
Power requirements
100-240V, 50/60Hz
Power consumption
50W
Dimensions
W
480mm (18-7/8″)
H
88mm (3-4/8″)
D
364mm (14-3/8″)
Net weight
5.7kg (12.6lbs)
Accessories
Owner’s Manual, Power Cord(2.5m), Rubber stoppers(4)
Others
Temperature Range: Operating temperature range: 0 – 40℃, Storage temperature range: -20 – 60℃
