| Current consumption |
0.9 A (XLR connector input), 0.3 A (PoE power supply) |
| Power Requirements |
12 V DC (10.8 V to 13.2 V) |
| Mass |
1.5 kg (3.31 lbs) |
| Dimensions (W x H x D) (mm) |
W 210 mm x H 92 mm x D 177 mm (excluding protrusions) |
| Dimensions (W x H x D) (inch) |
8-9/32 inches x 3-5/8 inches x 6-31/32 inches (excluding protrusions) |
| Display |
3.5-type liquid crystal (QHD 960 x 540) |
| Connection Specifications |
No. of Connectable Cameras :
200 (IP), 5 (RS422)
*Up to 100 for cameras other than the AW-UE150Remote Camera Selection :
5 (6 to 200 controlled from the LCD)No. of Camera Groups :
20 (10 units/group)
No. of Memory Presets :
100 |
| PoE* |
IEEE802.3af standard: 42 V to 57 V DC (Camera Input) |
| Note |
*PoE is the abbreviation for Power over Ethernet. |
